Please contact us for more photos of M8340109K1002FCD03
| Part Number | M8340109K1002FCD03 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 245990 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film NET 10K Ohm 1% 1.08W \u00b1100ppm \u00b0C BUS Molded 10-Pin SIP Pin Thru-Hole Tube |
| Category | Resistor |
| Family | Resistor Networks and Arrays |
| ROHS Compliant | Yes |
| MSL Level | M8340109K1002FCD03 |
| Datasheet download |  M8340109K1002FCD03.pdf |
| Part Number | M8340109K1002FCD03 |
|---|---|
| Resistance Value | 10 kOhm |
| Power Rating per Resistor | 3/25 W |
| Rad Hard | No |
| Case Style | Molded |
| Max Processing Temp | 260 |
| Terminal Pitch | 2.54 mm |
| Product Dimensions | 24.97 x 2.49 x 4.75 mm |
| Tolerance | 1 % |
| Lead Finish | Tin/Lead |
| Technology | Thick Film |
| Termination Style | Pin |
| Mounting | Through Hole |
| Power Rating | 1.08 W |
| Operating Temperature | -55 to 125 °C |
| Temperature Coefficient | ±100 ppm/°C |
| Product Depth | 2.49 mm |
| Product Height | 4.75 mm |
| Product Length | 24.97 mm |
| Product Weight | 600 mg |
| Replacement Part Number | PART-M8340109K1002FCD03 |
| Weight | Contact us |
| Country of Origin | - |
