IHLP2525CZER3R3M01 Vishay

IHLP2525CZER3R3M01 Images

Please contact us for more photos of IHLP2525CZER3R3M01

Part Number IHLP2525CZER3R3M01
Manufacturer Vishay
Quantity in stock 831120 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind High Current Shielded 3.3uH 20% 100KHz 6A 2525 T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level IHLP2525CZER3R3M01
Datasheet download IHLP2525CZER3R3M01.pdf
Request Quotation for IHLP2525CZER3R3M01

IHLP2525CZER3R3M01 Specifications

Part Number IHLP2525CZER3R3M01
Product Dimensions 7.24 x 6.72 x 3 mm
Package/Case 2525
Tolerance 20 %
Max Processing Temp 260
Rad Hard No
Test Frequency 100 kHz
Type High Current
Protection Style Shielded
Lead Finish Tin
Operating Temperature -55 to 125 °C
MSL Level 1
Product Depth 6.72 mm
Product Height 3 mm
Product Length 7.24 mm
Replacement Part Number PART-IHLP2525CZER3R3M01
Weight Contact us
Country of Origin -
