IHLP1616BZER2R2M11 Vishay

IHLP1616BZER2R2M11 Images

Please contact us for more photos of IHLP1616BZER2R2M11

Part Number IHLP1616BZER2R2M11
Manufacturer Vishay
Quantity in stock 101350 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind High Current Shielded Wirewound 2.2uH 20% 100KHz 3.25A 1616 T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level IHLP1616BZER2R2M11
Datasheet download IHLP1616BZER2R2M11.pdf
Request Quotation for IHLP1616BZER2R2M11

IHLP1616BZER2R2M11 Specifications

Part Number IHLP1616BZER2R2M11
Protection Style Shielded
Operating Temperature -55 to 125 °C
Lead Finish Tin
MSL Level 1
Package/Case 1616
Technology Wirewound
Rad Hard No
Tolerance 20 %
Max Processing Temp 260
Product Dimensions 4.7 x 4.31 x 2 mm
Type High Current
Test Frequency 100 kHz
Product Depth 4.31 mm
Product Height 2 mm
Product Length 4.7 mm
Replacement Part Number PART-IHLP1616BZER2R2M11
Weight Contact us
Country of Origin -
