Please contact us for more photos of ICM1206ER261M
| Part Number | ICM1206ER261M |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 179790 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Common Mode Choke Wirewound 260Ohm 20% 100MHz 310mA 1206 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | ICM1206ER261M |
| Datasheet download |  ICM1206ER261M.pdf |
| Part Number | ICM1206ER261M |
|---|---|
| Package/Case | 1206 |
| Product Dimensions | 3.4 x 1.8 x 2.1 mm |
| MSL Level | 1 |
| Test Frequency | 100 MHz |
| Lead Finish | Tin |
| Technology | Wirewound |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 85 °C |
| Tolerance | 20 % |
| Product Depth | 1.8 mm |
| Product Height | 2.1 mm |
| Product Length | 3.4 mm |
| Replacement Part Number | PART-ICM1206ER261M |
| Weight | Contact us |
| Country of Origin | - |
