Part Number | CRCW2512240KJNEG |
---|---|
Manufacturer | Vishay |
Quantity in stock | 865450 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Res Thick Film 2512 240K Ohm 5% 1W \u00b1200ppm \u00b0C Molded SMD SMD Blister T R |
Category | Resistor |
Family | Resistor Fixed Single-Surface Mount |
ROHS Compliant | Yes |
MSL Level | CRCW2512240KJNEG |
Datasheet download | ![]() |
Part Number | CRCW2512240KJNEG |
---|---|
Case Size | 2512 |
Mounting | Surface Mount |
Temperature Coefficient | ±200 ppm/°C |
Power Rating | 1 W |
Rad Hard | No |
Product Dimensions | 6.3 x 3.15 x 0.6 mm |
Resistance Value | 240 kOhm |
Lead Finish | Tin |
Max Processing Temp | 260 |
MSL Level | 1 |
Operating Temperature | -55 to 155 °C |
Case Style | Molded |
Tolerance | 5 % |
Product Depth | 3.15 mm |
Product Height | 0.6 mm |
Product Length | 6.3 mm |
Product Weight | 40.5 mg |
Replacement Part Number | PART-CRCW2512240KJNEG |
Weight | Contact us |
Country of Origin | - |
