Please contact us for more photos of 594D106X9025B2T
| Part Number | 594D106X9025B2T |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 281590 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 10uF 25V B CASE 10% (4 X 2.8 X 1.9mm) SMD T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | 594D106X9025B2T |
| Datasheet download |  594D106X9025B2T.pdf |
| Part Number | 594D106X9025B2T |
|---|---|
| Polarity | Polar |
| Case Style | Conformal Coated |
| Product Dimensions | 4 x 2.8 x 1.9 mm |
| Leakage Current | 2.5 uA |
| Lead Finish | Tin |
| Equivalent Series Resistance | 0.9 Ohm |
| Tolerance | 10 % |
| Operating Temperature | -55 to 125 °C |
| Dissipation Factor | 6 % |
| Capacitance Value | 10 uF |
| MSL Level | 2a |
| Max Processing Temp | 250 to 260|260 |
| Mounting | Surface Mount |
| Construction | Flat |
| Voltage(DC) | 25 V |
| Case Code | B |
| Package/Case | B |
| Product Depth | 2.8 mm |
| Product Height | 1.9 mm |
| Product Length | 4(Max) mm |
| Replacement Part Number | PART-594D106X9025B2T |
| Weight | Contact us |
| Country of Origin | - |
