| Part Number | HCNW4502-500E |
|---|---|
| Manufacturer | Broadcom |
| Quantity in stock | 106380 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Optocoupler DC-IN 1-CH Transistor With Base DC-OUT 8-Pin CDIP W SMD T R |
| Category | Optoelectronics |
| Family | OptoCouplers |
| ROHS Compliant | Yes |
| MSL Level | HCNW4502-500E |
| Datasheet download |  HCNW4502-500E.pdf |
| Part Number | HCNW4502-500E |
|---|---|
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Output Type | DC |
| Maximum Reverse Voltage | 3 V |
| Product Dimensions | 11.15 x 9 x 4 mm |
| Maximum Collector Current | 8 mA |
| Input Type | DC |
| Number of Channels per Chip | 1 |
| Maximum Power Dissipation | 100 mW |
| Pin Count | 8 |
| MSL Level | 1 |
| Maximum Forward Voltage | 1.85 V |
| Typical Forward Voltage | 1.68 V |
| Minimum Forward Voltage | 1.45 V |
| Minimum Isolation Voltage | 5000 Vrms |
| Supplier Package | CDIP W SMD |
| Rad Hard | No |
| Maximum Input Current | 25 mA |
| Max Processing Temp | 260 |
| Operating Temperature | -55 to 85 °C |
| Maximum Current Transfer Ratio @ Current | 50 % |
| Package | 8CDIP W SMD |
| Replacement Part Number | PART-HCNW4502-500E |
| Weight | Contact us |
| Country of Origin | - |
