Part Number | 7201K12CQE |
---|---|
Manufacturer | C&K |
Quantity in stock | 397280 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Switch Toggle ON None ON DPDT Locking Lever PC Pins 5A 250VAC 28VDC PC Mount with Threads |
Category | Switches and Relays |
Family | Switches |
ROHS Compliant | Yes |
MSL Level | 7201K12CQE |
Datasheet download | ![]() |
Part Number | 7201K12CQE |
---|---|
Base/Housing Material | N/A/Stainless Steel |
Contact Plating | Silver |
Product Dimensions | 12.7 x 11.43 x 37.54 mm |
Contact Material | Coin Silver |
Lead Finish | Silver |
Operating Temperature | -30 to 85 °C |
Mounting | PC Mount with Threads |
Rad Hard | No |
Switch Configuration | ON None ON |
Pole Throw Configuration | DPDT |
Replacement Part Number | PART-7201K12CQE |
Weight | Contact us |
Country of Origin | - |
