TPS76130DBVT Texas Instruments

TPS76130DBVT Images

Please contact us for more photos of TPS76130DBVT

Part Number TPS76130DBVT
Manufacturer Texas Instruments
Quantity in stock 211390 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description LDO Regulator Pos 3V 0.1A 5-Pin SOT-23 T R
Category Power Management IC
Family Linear Regulator
ROHS Compliant Yes
MSL Level TPS76130DBVT
Datasheet download TPS76130DBVT.pdf
Request Quotation for TPS76130DBVT

TPS76130DBVT Specifications

Part Number TPS76130DBVT
Output Type Fixed
Junction to Ambient 259 °C/W
Maximum Output Current 0.1 A
Mounting Surface Mount
Output Voltage 3 V
Minimum Input Voltage 3.35 V
Function LDO
Number of Outputs 1
Product Dimensions 2.9 x 1.6 x 1.15 mm
Maximum Input Voltage 16 V
Typical Quiescent Current 0.09 mA
Typical Dropout Voltage @ Current 0.001@0mA|0.17@100mA|0.12@50mA|0.04@10mA|0.007@1mA V
MSL Level 1
Screening Level Automotive
Supplier Package SOT-23
Pin Count 5
Polarity Positive
Operating Temperature -40 to 125 °C
Junction to Case 65.8 °C/W
Lead Finish Gold
Rad Hard No
Max Processing Temp 260
Maximum Quiescent Current 0.115 mA
Line Regulation 10 mV
Accuracy ±2 %
Maximum Power Dissipation 555 mW
Maximum Dropout Voltage @ Current 0.003@0mA|0.24@100mA|0.15@50mA|0.06@10mA|0.01@1mA V
Input Voltage Range 16 to 3.35 V
Package 5SOT-23
Replacement Part Number PART-TPS76130DBVT
Weight Contact us
Country of Origin -
