Please contact us for more photos of TPS75718KTTR
| Part Number | TPS75718KTTR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 347950 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | LDO Regulator Pos 1.8V 3A 6-Pin(5+Tab) TO-263 T R |
| Category | Power Management IC |
| Family | Linear Regulator |
| ROHS Compliant | Yes |
| MSL Level | TPS75718KTTR |
| Datasheet download |  TPS75718KTTR.pdf |
| Part Number | TPS75718KTTR |
|---|---|
| Screening Level | Extended |
| Load Regulation | 0.35 %/V |
| Rad Hard | No |
| Input Voltage Range | 5.5 to 2.8 V |
| MSL Level | 2 |
| Output Voltage | 1.8 V |
| Pin Count | 6 |
| Typical Dropout Voltage @ Current | 0.15@3A V |
| Line Regulation | 0.04 %/V |
| Number of Outputs | 1 |
| Function | LDO |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Lead Finish | Matte Tin |
| Product Dimensions | 10.16 x 8.42 x 4.58 mm |
| Output Type | Fixed |
| Polarity | Positive |
| Junction to Case | 2 °C/W |
| Supplier Package | TO-263 |
| Minimum Input Voltage | 2.8 V |
| Accuracy | ±3 % |
| Maximum Output Current | 3 A |
| Maximum Input Voltage | 5.5 V |
| Junction to Ambient | 38.7 °C/W |
| Maximum Quiescent Current | 0.2 mA |
| Typical Quiescent Current | 0.125 mA |
| Operating Temperature | -40 to 125 °C |
| Package | 6TO-263 |
| Replacement Part Number | PART-TPS75718KTTR |
| Weight | Contact us |
| Country of Origin | - |
