TPS73633DBVTG4 Texas Instruments

TPS73633DBVTG4 Images

Please contact us for more photos of TPS73633DBVTG4

Part Number TPS73633DBVTG4
Manufacturer Texas Instruments
Quantity in stock 223940 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description LDO Regulator Pos 3.3V 0.4A 5-Pin SOT-23 T R
Category Power Management IC
Family Linear Regulator
ROHS Compliant Yes
MSL Level TPS73633DBVTG4
Datasheet download TPS73633DBVTG4.pdf
Request Quotation for TPS73633DBVTG4

TPS73633DBVTG4 Specifications

Part Number TPS73633DBVTG4
Minimum Input Voltage 1.7 V
Junction to Ambient 180 °C/W
Function LDO
Load Regulation 0.002 %/mA
Rad Hard No
Number of Outputs 1
Maximum Output Current 0.4 A
Line Regulation 0.01 %/V
Maximum Dropout Voltage @ Current 0.2@400mA V
Mounting Surface Mount
Max Processing Temp 260
Pin Count 5
Lead Finish Matte Tin
MSL Level 1
Accuracy ±0.5 %
Junction to Case 64 °C/W
Maximum Input Voltage 5.5 V
Supplier Package SOT-23
Input Voltage Range 5.5 to 1.7 V
Typical Quiescent Current 0.3 mA
Polarity Positive
Output Type Fixed
Typical Dropout Voltage @ Current 0.075@400mA V
Product Dimensions 2.9 x 1.6 x 1.15 mm
Output Voltage 3.3 V
Operating Temperature -40 to 125 °C
Package 5SOT-23
Replacement Part Number PART-TPS73633DBVTG4
Weight Contact us
Country of Origin -
