Please contact us for more photos of TPS62740DSSR
| Part Number | TPS62740DSSR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 483630 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 2.2V to 5.5V 12-Pin WSON T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | TPS62740DSSR |
| Datasheet download |  TPS62740DSSR.pdf |
| Part Number | TPS62740DSSR |
|---|---|
| Minimum Input Voltage | 2.2 V |
| Load Regulation | 0.001(Typ) %/mA |
| Output Type | Adjustable |
| Maximum Input Voltage | 5.5 V |
| Switching Regulator | Yes |
| Supplier Package | WSON |
| Product Dimensions | 2 x 3 x 0.75(Max) |
| Screening Level | Industrial |
| Lead Finish | Gold Over Nickel Palladium |
| Output Voltage | 1.8 to 3.3 V |
| Line Regulation | 0(Typ) %/V |
| Maximum Output Current | 0.3 A |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Type | Step Down |
| MSL Level | 2 |
| Operating Supply Voltage | 2.2 to 5.5 V |
| Pin Count | 12 |
| Switching Frequency | 2000 kHz |
| Efficiency | 90 % |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Number of Outputs | 1 |
| Package | 12WSON |
| Replacement Part Number | PART-TPS62740DSSR |
| Weight | Contact us |
| Country of Origin | - |
