Please contact us for more photos of TPD1E10B09DPYR
| Part Number | TPD1E10B09DPYR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 704020 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Single Channel ESD Protection Device 2-Pin X2-SON T R |
| Category | Interface IC |
| Family | Interface Misc |
| ROHS Compliant | Yes |
| MSL Level | TPD1E10B09DPYR |
| Datasheet download |  TPD1E10B09DPYR.pdf |
| Part Number | TPD1E10B09DPYR |
|---|---|
| Type | Single Channel ESD Protection Device |
| Supplier Package | X2SON |
| Category | Single Channel ESD Protection Device |
| Lead Finish | Gold |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Operating Temperature | -40 to 125 °C |
| Pin Count | 2 |
| Product Dimensions | 1.1 x 0.7 x 0.35 mm |
| Mounting | Surface Mount |
| Screening Level | Industrial |
| MSL Level | 1 |
| Package | 2X2-SON |
| Replacement Part Number | PART-TPD1E10B09DPYR |
| Weight | Contact us |
| Country of Origin | - |
