Please contact us for more photos of TPA2028D1YZFR
| Part Number | TPA2028D1YZFR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 576210 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Audio Amp Speaker 1-CH Mono 3W Class-D 9-Pin DS-BGA T R |
| Category | Amplifiers IC |
| Family | Audio Amplifier |
| ROHS Compliant | Yes |
| MSL Level | TPA2028D1YZFR |
| Datasheet download |  TPA2028D1YZFR.pdf |
| Part Number | TPA2028D1YZFR |
|---|---|
| Supplier Package | DSBGA |
| Maximum Supply Current | [email protected] mA |
| Input Signal Type | Differential |
| Maximum Single Supply Voltage | 5.5 V |
| Power Supply Type | Single |
| Amplifier Type | Class-D |
| Total Harmonic Distortion Noise | 1@[email protected]|0.1@8Ohm@550mW % |
| Typical Supply Current | [email protected] mA |
| Pin Count | 9 |
| Rail to Rail | No |
| Typical PSRR | 80 dB |
| Output Signal Type | Differential |
| Typical Single Supply Voltage | 3.6 V |
| Maximum Load Resistance | 8 Ohm |
| Rad Hard | No |
| Mounting | Surface Mount |
| Output Type | 1-Channel Mono |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 85 °C |
| MSL Level | 1 |
| Minimum CMRR | 75 dB |
| Product Dimensions | 1.8 x 1.8 x 0.35 mm |
| Maximum Power Dissipation | 1190 mW |
| Function | Speaker |
| Lead Finish | Tin/Silver/Copper |
| Typical Output Power x Channels @ Load | 3x1@4Ohm W |
| Minimum Single Supply Voltage | 2.5 V |
| Package | 9DS-BGA |
| Replacement Part Number | PART-TPA2028D1YZFR |
| Weight | Contact us |
| Country of Origin | - |
