Please contact us for more photos of TLV2461IP
| Part Number | TLV2461IP |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 735060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Single GP R-R I O \u00b13V 6V 8-Pin PDIP Tube |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | TLV2461IP |
| Datasheet download |  TLV2461IP.pdf |
| Part Number | TLV2461IP |
|---|---|
| Supplier Package | PDIP |
| Maximum Power Dissipation | 1200 mW |
| Maximum Input Offset Voltage | 2@5V mV |
| Minimum Single Supply Voltage | 2.7 V |
| Lead Finish | Gold |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Minimum Dual Supply Voltage | ±1.35 V |
| Operating Temperature | -40 to 125 °C |
| Rail to Rail | Rail to Rail Input/Output |
| Typical NonInverting Input Noise Current Density | 0.13@5V pA/rtHz |
| Typical Single Supply Voltage | 3|5 V |
| Power Supply Type | Single|Dual |
| Maximum Operating Supply Voltage | ±3|6 V |
| Maximum Single Supply Voltage | 6 V |
| Product Dimensions | 9.81 x 6.35 x 4.57 mm |
| Type | General Purpose Amplifier |
| Maximum Supply Current | 0.65@5V mA |
| Typical Input Noise Voltage Density | 14@5V nV/rtHz |
| Number of Channels per Chip | 1 |
| Shut Down Support | No |
| Maximum Dual Supply Voltage | ±3 V |
| Typical Slew Rate | 1.6@5V V/us |
| Pin Count | 8 |
| Maximum Input Bias Current | 0.014@5V uA |
| Screening Level | Industrial |
| Minimum CMRR | 71 dB |
| Mounting | Through Hole |
| Typical Voltage Gain | 109 dB |
| Typical Gain Bandwidth Product | 6.4 MHz |
| Package | 8PDIP |
| Replacement Part Number | PART-TLV2461IP |
| Weight | Contact us |
| Country of Origin | - |
