Please contact us for more photos of TLC2272ACDG4
| Part Number | TLC2272ACDG4 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 705260 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Dual GP R-R O P \u00b18V 16V 8-Pin SOIC Tube |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | TLC2272ACDG4 |
| Datasheet download |  TLC2272ACDG4.pdf |
| Part Number | TLC2272ACDG4 |
|---|---|
| Typical Slew Rate | 3.6@5V V/us |
| Minimum Single Supply Voltage | 4.4 V |
| Maximum Input Offset Voltage | 0.95@±2.5V mV |
| Typical NonInverting Input Noise Current Density | 0.0006@5V pA/rtHz |
| Max Processing Temp | 260 |
| Lead Finish | Gold |
| Maximum Dual Supply Voltage | ±8 V |
| Maximum Operating Supply Voltage | ±8|16 V |
| Typical Dual Supply Voltage | ±3|±5 V |
| Rad Hard | No |
| Operating Temperature | 0 to 70 °C |
| Maximum Single Supply Voltage | 16 V |
| Minimum CMRR | 70 dB |
| Maximum Input Bias Current | 0.00006@±2.5V uA |
| Mounting | Surface Mount |
| Maximum Supply Current | 3@5V mA |
| Typical Gain Bandwidth Product | 2.18 MHz |
| Type | General Purpose Amplifier |
| Power Supply Type | Single|Dual |
| Rail to Rail | Rail to Rail Output |
| Minimum Dual Supply Voltage | ±2.2 V |
| Shut Down Support | No |
| Typical Voltage Gain | 104.86 dB |
| Typical Single Supply Voltage | 5|9|12|15 V |
| Pin Count | 8 |
| MSL Level | 1 |
| Typical Input Noise Voltage Density | 50@5V nV/rtHz |
| Supplier Package | SOIC |
| Technology | LinCMOS |
| Number of Channels per Chip | 2 |
| Product Dimensions | 4.9 x 3.91 x 1.58 mm |
| Package | 8SOIC |
| Replacement Part Number | PART-TLC2272ACDG4 |
| Weight | Contact us |
| Country of Origin | - |
