TAS5631BPHDR Texas Instruments

TAS5631BPHDR Images

Please contact us for more photos of TAS5631BPHDR

Part Number TAS5631BPHDR
Manufacturer Texas Instruments
Quantity in stock 558680 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Audio Amp Speaker 1-CH Mono 2-CH Stereo 4-CH Stereo 600W Class-D 64-Pin HTQFP EP T R
Category Amplifiers IC
Family Audio Amplifier
ROHS Compliant Yes
MSL Level TAS5631BPHDR
Datasheet download TAS5631BPHDR.pdf
Request Quotation for TAS5631BPHDR

TAS5631BPHDR Specifications

Part Number TAS5631BPHDR
Amplifier Type Class-D
Minimum Dual Supply Voltage 10.8|25 V
Mounting Surface Mount
Maximum Load Resistance 8 Ohm
Typical Dual Supply Voltage 12|50 V
Output Signal Type Differential|Single
Typical PSRR 80 dB
Power Supply Type Triple
Product Dimensions 14 x 14 x 1 mm
Input Signal Type Differential|Single
Total Harmonic Distortion Noise 0.03@4Ohm@1W %
Output Type 1-Channel Mono|2-Channel Stereo|4-Channel Stereo
Typical Supply Current 22.5@12V@75C/12.5@12V@75C/19.5@50V@75C mA
Typical Output Power x Channels @ Load 600x1@2Ohm|300x1@4Ohm|300x2@4Ohm|145x2@2Ohm|145x4@2Ohm W
Operating Temperature 0 to 70 °C
Max Processing Temp 260
Lead Finish Gold
Rail to Rail No
Function Speaker
MSL Level 4
Maximum Dual Supply Voltage 52.5|13.2 V
Pin Count 64
Supplier Package HTQFP EP
Maximum Output Current 9 mA
Package 64HTQFP EP
Replacement Part Number PART-TAS5631BPHDR
Weight Contact us
Country of Origin -
