Please contact us for more photos of PTN78020WAD
| Part Number | PTN78020WAD |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 348680 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Module DC-DC 1-OUT 2.5V to 12.6V 6A 90W 7-Pin DIP Module |
| Category | Power Supplies |
| Family | DC to DC Power Supply |
| ROHS Compliant | Yes |
| MSL Level | PTN78020WAD |
| Datasheet download |  PTN78020WAD.pdf |
| Part Number | PTN78020WAD |
|---|---|
| Output Power | 90 W |
| Output Voltage | 2.5 to 12.6 V |
| Switching Regulator | Yes |
| Number of Outputs | 1 |
| Input Voltage | 7 to 36 V |
| Output Current | 6 A |
| Product Dimensions | 37.97 x 22.1 x 8.75 mm |
| Mounting | Through Hole |
| Type | Step Down |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Supplier Package | DIP Module |
| Pin Count | 7 |
| Package | 7DIP Module |
| Replacement Part Number | PART-PTN78020WAD |
| Weight | Contact us |
| Country of Origin | - |
| Image | Part Number and Brand | Brief Description and PDF Datasheet |
|---|---|---|
|
Texas Instruments | Module DC-DC 1-OUT -15V to -3V 3A 15W 7-Pin DIP Module T R Download PDF datasheet for PTN78060AAST.pdf |
|
Texas Instruments | Module DC-DC 1-OUT 0.69V to 5.5V 3A 10-Pin DIP Module Download PDF datasheet for PTH08T260WAD.pdf |
|
GE Critical Power | Module DC-DC 1-OUT 28V 16A 450W 9-Pin Half-Brick Download PDF datasheet for JRCW016A0R641-18Z.pdf |
|
GE Critical Power | Module DC-DC 1-OUT 12V 20A 240W 15-Pin 1 8-Brick Tray Download PDF datasheet for EBDW020A0B641-HZ.pdf |
|
Ericsson | Module DC-DC 1-OUT 3.3V 15A 50W 8-Pin Quarter-Brick Tray Download PDF datasheet for PKM2510EPIPLA.pdf |
|
GE Critical Power | DC-DC POWER MODULE - |
|
Texas Instruments | Module DC-DC 1-OUT 0.69V to 5.5V 16A 11-Pin DIP Module Tray Download PDF datasheet for PTH08T220WAS.pdf |
|
Murata Manufacturing | Module DC-DC 1-OUT 3.4V 7.3A 25W 4-Pin Tube Download PDF datasheet for NPH25S2403iC.pdf |
|
GE Critical Power | Module DC-DC 1-OUT 0.75V to 3.63V 10A 6-Pin SMT T R Download PDF datasheet for AXH010A0X3SRZ.pdf |
|
Texas Instruments | Module DC-DC 2-OUT 5V -5V 0.1A -0.1A 1W 5-Pin SIP Module Tray Download PDF datasheet for DCH010505DN7.pdf |
