PTN78000AAH Texas Instruments

PTN78000AAH Images

Please contact us for more photos of PTN78000AAH

Part Number PTN78000AAH
Manufacturer Texas Instruments
Quantity in stock 821510 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Module DC-DC 1-OUT -15V to -3V 1.5A 5-Pin DIP Module
Category Power Supplies
Family DC to DC Power Supply
ROHS Compliant Yes
MSL Level PTN78000AAH
Datasheet download PTN78000AAH.pdf
Request Quotation for PTN78000AAH

PTN78000AAH Specifications

Part Number PTN78000AAH
Switching Regulator Yes
Pin Count 5
Output Current 1.5 A
Mounting Through Hole
Number of Outputs 1
Output Voltage -15 to -3 V
Lead Finish Tin
Input Voltage 7 to 29 V
Product Dimensions 18.92 x 12.57 x 8.25 mm
Supplier Package DIP Module
Rad Hard No
Type Non-Inverting|Inverting|Step Up|Step Down
Package 5DIP Module
Replacement Part Number PART-PTN78000AAH
Weight Contact us
Country of Origin -
