PTH12000WAH Texas Instruments

PTH12000WAH Images

Please contact us for more photos of PTH12000WAH

Part Number PTH12000WAH
Manufacturer Texas Instruments
Quantity in stock 347690 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Module DC-DC 1-OUT 1.2V to 5.5V 6A 5-Pin DIP Module
Category Power Supplies
Family DC to DC Power Supply
ROHS Compliant Yes
MSL Level PTH12000WAH
Datasheet download PTH12000WAH.pdf
Request Quotation for PTH12000WAH

PTH12000WAH Specifications

Part Number PTH12000WAH
Input Voltage 12(TYP) V
Rad Hard No
Type Step Down
Switching Regulator No
Supplier Package DIP Module
Product Dimensions 18.92 x 12.57 x 8.25 mm
Number of Outputs 1
Lead Finish Matte Tin
Pin Count 5
Mounting Through Hole
Output Current 6 A
Output Voltage 1.2 to 5.5 V
Package 5DIP Module
Replacement Part Number PART-PTH12000WAH
Weight Contact us
Country of Origin -
