PTH05000WAH Texas Instruments

PTH05000WAH Images

Please contact us for more photos of PTH05000WAH

Part Number PTH05000WAH
Manufacturer Texas Instruments
Quantity in stock 269840 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Module DC-DC 1-OUT 0.9V to 3.6V 6A 5-Pin DIP Module
Category Power Supplies
Family DC to DC Power Supply
ROHS Compliant Yes
MSL Level PTH05000WAH
Datasheet download PTH05000WAH.pdf
Request Quotation for PTH05000WAH

PTH05000WAH Specifications

Part Number PTH05000WAH
Rad Hard No
Type Step Down
Product Dimensions 18.92 x 12.57 x 8.25 mm
Switching Regulator No
Supplier Package DIP Module
Pin Count 5
Input Voltage 5(TYP) V
Lead Finish Matte Tin
Mounting Through Hole
Number of Outputs 1
Output Current 6 A
Output Voltage 0.9 to 3.6 V
Package 5DIP Module
Replacement Part Number PART-PTH05000WAH
Weight Contact us
Country of Origin -
