Please contact us for more photos of OPA2336UA 2K5
| Part Number | OPA2336UA 2K5 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 365700 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Dual GP R-R O P 5.5V 8-Pin SOIC T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | OPA2336UA 2K5 |
| Datasheet download |  OPA2336UA 2K5.pdf |
| Part Number | OPA2336UA 2K5 |
|---|---|
| Minimum Single Supply Voltage | 2.3 V |
| Typical Single Supply Voltage | 3|5 V |
| Minimum CMRR | 76 dB |
| Typical Input Noise Voltage Density | 40@5V nV/rtHz |
| MSL Level | 2 |
| Technology | CMOS |
| Maximum Input Bias Current | [email protected] uA |
| Maximum Single Supply Voltage | 5.5 V |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Lead Finish | Gold |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Mounting | Surface Mount |
| Number of Channels per Chip | 2 |
| Typical NonInverting Input Noise Current Density | 0.03@5V pA/rtHz |
| Maximum Input Offset Voltage | [email protected] mV |
| Type | General Purpose Amplifier |
| Typical Voltage Gain | 115 dB |
| Power Supply Type | Single |
| Typical Gain Bandwidth Product | 0.1 MHz |
| Maximum Operating Supply Voltage | 5.5 V |
| Shut Down Support | No |
| Rail to Rail | Rail to Rail Output |
| Pin Count | 8 |
| Supplier Package | SOIC |
| Minimum PSRR | 92.04 dB |
| Typical Slew Rate | 0.03@5V V/us |
| Package | 8SOIC |
| Replacement Part Number | PART-OPA2336UA 2K5 |
| Weight | Contact us |
| Country of Origin | - |
