Please contact us for more photos of OPA2237UA 2K5
| Part Number | OPA2237UA 2K5 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 443000 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Dual GP \u00b118V 36V 8-Pin SOIC T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | OPA2237UA 2K5 |
| Datasheet download |  OPA2237UA 2K5.pdf |
| Part Number | OPA2237UA 2K5 |
|---|---|
| Maximum Dual Supply Voltage | ±18 V |
| Number of Channels per Chip | 2 |
| Typical Voltage Gain | 88 dB |
| Typical Dual Supply Voltage | ±15 V |
| Minimum CMRR | 78 dB |
| Power Supply Type | Single|Dual |
| Type | General Purpose Amplifier |
| Mounting | Surface Mount |
| Maximum Operating Supply Voltage | ±18|36 V |
| Shut Down Support | No |
| Maximum Input Bias Current | 0.04@5V uA |
| Minimum Single Supply Voltage | 2.7 V |
| Typical NonInverting Input Noise Current Density | 0.06@5V pA/rtHz |
| Pin Count | 8 |
| Typical Single Supply Voltage | 5 V |
| Supplier Package | SOIC |
| Rail to Rail | No |
| Typical Gain Bandwidth Product | 1.4 MHz |
| Typical Input Noise Voltage Density | 28@5V nV/rtHz |
| Typical Slew Rate | 0.5@5V V/us |
| Maximum Single Supply Voltage | 36 V |
| Minimum Dual Supply Voltage | ±1.35 V |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Lead Finish | Gold |
| Product Dimensions | 5 x 4 x 1.5 mm |
| MSL Level | 3 |
| Maximum Input Offset Voltage | 0.75@5V mV |
| Package | 8SOIC |
| Replacement Part Number | PART-OPA2237UA 2K5 |
| Weight | Contact us |
| Country of Origin | - |
