MSP430G2403IPW28R Texas Instruments

MSP430G2403IPW28R Images

Please contact us for more photos of MSP430G2403IPW28R

Part Number MSP430G2403IPW28R
Manufacturer Texas Instruments
Quantity in stock 165750 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description MCU 16-bit MSP430 RISC 8KB Flash 2.5V 3.3V 28-Pin TSSOP T R
Category Microcontrollers MCU IC
Family 16 Bit Microcontrollers MCU
ROHS Compliant Yes
MSL Level MSP430G2403IPW28R
Datasheet download MSP430G2403IPW28R.pdf
Request Quotation for MSP430G2403IPW28R

MSP430G2403IPW28R Specifications

Part Number MSP430G2403IPW28R
Program Memory Size 8 KB
Operating Temperature -40 to 85 °C
Product Dimensions 9.8 x 4.5 x 1.05 mm
Number of Timers 2
RAM Size 512 byte
Program Memory Type Flash
Pin Count 28
Number of Programmable I/Os 24
Data Bus Width 16 Bits
Operating Supply Voltage 2.5|3.3 V
Minimum Operating Supply Voltage 1.8 V
Max Processing Temp 260
Watchdog 1
Device Core
LCD Segments
Display Driver
Maximum Operating Supply Voltage 3.6 V
Supplier Package TSSOP
Rad Hard No
MSL Level 1
Interface Type I2C/SPI/UART
Instruction Set Architecture RISC
Maximum Speed 16 MHz
Mounting Surface Mount
Lead Finish Gold
Package 28TSSOP
Replacement Part Number PART-MSP430G2403IPW28R
Weight Contact us
Country of Origin -
