Please contact us for more photos of LMP8645HVMKX NOPB
| Part Number | LMP8645HVMKX NOPB |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 109780 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp Current Sense Amp Single 12V 6-Pin TSOT T R |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | LMP8645HVMKX NOPB |
| Datasheet download |  LMP8645HVMKX NOPB.pdf |
| Part Number | LMP8645HVMKX NOPB |
|---|---|
| Minimum Single Supply Voltage | 2.7 V |
| Lead Finish | Gold |
| Product Dimensions | 2.97 x 1.65 x 0.87 mm |
| Minimum PSRR | 90 dB |
| Minimum CMRR | 95 dB |
| Maximum Input Bias Current | 22@5V uA |
| Maximum Supply Current | 2.8@5V mA |
| Power Supply Type | Single |
| Supplier Package | TSOT |
| Type | Current Sense Amplifier |
| Pin Count | 6 |
| Maximum Single Supply Voltage | 12 V |
| Rad Hard | No |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Rail to Rail | No |
| Number of Channels per Chip | 1 |
| Mounting | Surface Mount |
| Operating Temperature | -40 to 125 °C |
| Package | 6TSOT |
| Replacement Part Number | PART-LMP8645HVMKX NOPB |
| Weight | Contact us |
| Country of Origin | - |
