LMP7715MF NOPB Texas Instruments

Please contact us for more photos of LMP7715MF NOPB

Part Number	LMP7715MF NOPB
Manufacturer	Texas Instruments
Quantity in stock	302660 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	OP Amp Single GP R-R O P 5.5V 5-Pin SOT-23 T R
Category	Amplifiers IC
Family	OP Amp
ROHS Compliant	Yes
MSL Level	LMP7715MF NOPB
Datasheet download	LMP7715MF NOPB.pdf

Request Quotation for LMP7715MF NOPB

LMP7715MF NOPB Specifications

Part Number	LMP7715MF NOPB
Minimum CMRR	85 dB
Maximum Input Offset Voltage	0.15@5V mV
Maximum Supply Current	1.4@5V mA
Typical Slew Rate	11.5@5V V/us
Minimum Single Supply Voltage	1.8 V
Maximum Single Supply Voltage	5.5 V
Operating Temperature	-40 to 125 °C
Max Processing Temp	260
Rad Hard	No
Minimum PSRR	85 dB
Typical Voltage Gain	110 dB
Product Dimensions	2.92 x 1.6 x 1.02 mm
Power Supply Type	Single
Typical Single Supply Voltage	3\|5 V
Typical Input Noise Voltage Density	7@5V nV/rtHz
Pin Count	5
Typical NonInverting Input Noise Current Density	0.01@5V pA/rtHz
Mounting	Surface Mount
Rail to Rail	Rail to Rail Output
Type	General Purpose Amplifier
Lead Finish	Tin
Maximum Input Bias Current	0.000001@5V uA
Shut Down Support	No
MSL Level	1
Maximum Operating Supply Voltage	5.5 V
Typical Gain Bandwidth Product	17 MHz
Supplier Package	SOT-23
Number of Channels per Chip	1
Package	5SOT-23
Replacement Part Number	PART-LMP7715MF NOPB
Weight	Contact us
Country of Origin	-
