Please contact us for more photos of LM3152MH-3.3 NOPB
| Part Number | LM3152MH-3.3 NOPB |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 727400 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | DC DC Cntrlr Single-OUT Sync Step Down 6V to 33V Input 14-Pin TSSOP EP Tube |
| Category | Power Management IC |
| Family | DC to DC Controller |
| ROHS Compliant | Yes |
| MSL Level | LM3152MH-3.3 NOPB |
| Datasheet download |  LM3152MH-3.3 NOPB.pdf |
| Part Number | LM3152MH-3.3 NOPB |
|---|---|
| Type | Synchronous Step Down Controller |
| Output Voltage | 3.3 V |
| Product Dimensions | 5 x 4.4 x 0.9 mm |
| Operating Temperature | -40 to 125 °C |
| Supplier Package | TSSOP EP |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Mounting | Surface Mount |
| Pin Count | 14 |
| Output Current | 12 A |
| Lead Finish | Tin |
| Operating Supply Voltage | 6 to 33 V |
| MSL Level | 1 |
| Input Voltage | 6 to 33 V |
| Number of Outputs | 1 |
| Package | 14TSSOP EP |
| Replacement Part Number | PART-LM3152MH-3.3 NOPB |
| Weight | Contact us |
| Country of Origin | - |
