LM2941CSX NOPB Texas Instruments

LM2941CSX NOPB Images

Please contact us for more photos of LM2941CSX NOPB

Part Number LM2941CSX NOPB
Manufacturer Texas Instruments
Quantity in stock 469620 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description LDO Regulator Pos 5V to 20V 1A 6-Pin(5+Tab) TO-263 T R
Category Power Management IC
Family Linear Regulator
ROHS Compliant Yes
MSL Level LM2941CSX NOPB
Datasheet download LM2941CSX NOPB.pdf
Request Quotation for LM2941CSX NOPB

LM2941CSX NOPB Specifications

Part Number LM2941CSX NOPB
Junction to Case 3 °C/W
Line Regulation 10 mV/V
Rad Hard No
Operating Temperature 0 to 125 °C
Product Dimensions 10.16 x 8.64 x 4.57 mm
Maximum Output Current 1 A
Minimum Input Voltage -15 V
Pin Count 6
Typical Dropout Voltage @ Current 0.11@100mA|0.5@1A V
Number of Outputs 1
Max Processing Temp 260
Mounting Surface Mount
Function LDO
MSL Level 3
Maximum Input Voltage 26 V
Lead Finish Matte Tin
Output Voltage 5 to 20 V
Reference Voltage 1.313 V
Input Voltage Range 26 to -15 V
Maximum Dropout Voltage @ Current 0.2@100mA|0.8@1A V
Typical Quiescent Current 10 mA
Supplier Package TO-263
Polarity Positive
Output Type Adjustable
Maximum Quiescent Current 15 mA
Load Regulation 10 mV/V
Junction to Ambient 73 °C/W
Package 6TO-263
Replacement Part Number PART-LM2941CSX NOPB
Weight Contact us
Country of Origin -
