| Part Number | LM224J |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 569870 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Quad GP \u00b116V 32V 14-Pin CDIP Rail |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | LM224J |
| Datasheet download |  LM224J.pdf |
| Part Number | LM224J |
|---|---|
| Minimum PSRR | 65 dB |
| Operating Temperature | -25 to 85 °C |
| Supplier Package | CDIP |
| Typical NonInverting Input Noise Current Density | 0.1 pA/rtHz |
| Maximum Input Bias Current | 0.15@5V uA |
| Maximum Supply Current | 1.2@5V@-25C to 85C mA |
| Typical Voltage Gain | 100 dB |
| Rad Hard | No |
| Maximum Operating Supply Voltage | ±16|32 V |
| Typical Slew Rate | 0.5 V/us |
| Rail to Rail | No |
| Maximum Single Supply Voltage | 32 V |
| Minimum CMRR | 70 dB |
| Maximum Dual Supply Voltage | ±16 V |
| Pin Count | 14 |
| Technology | Bipolar |
| Power Supply Type | Single|Dual |
| Type | General Purpose Amplifier |
| Minimum Single Supply Voltage | 3 V |
| Typical Dual Supply Voltage | ±3|±5|±9|±12|±15 V |
| Shut Down Support | No |
| Typical Single Supply Voltage | 5|9|12|15|18|24|28 V |
| Number of Channels per Chip | 4 |
| MSL Level | 1 |
| Minimum Dual Supply Voltage | ±1.5 V |
| Maximum Power Dissipation | 1260 mW |
| Product Dimensions | 19.94 x 7.87 x 4.57 mm |
| Lead Finish | Tin/Lead |
| Mounting | Through Hole |
| Package | 14CDIP |
| Replacement Part Number | PART-LM224J |
| Weight | Contact us |
| Country of Origin | - |
