Please contact us for more photos of INA194AQDBVRQ1
| Part Number | INA194AQDBVRQ1 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 675590 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp Current Shunt Monitor Single 18V 5-Pin SOT-23 T R |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | INA194AQDBVRQ1 |
| Datasheet download |  INA194AQDBVRQ1.pdf |
| Part Number | INA194AQDBVRQ1 |
|---|---|
| Maximum Input Bias Current | 23@12V@-40C to 125C uA |
| Maximum Voltage Gain | 33.98 dB |
| Type | Current Shunt Monitor |
| Minimum Single Supply Voltage | 2.7 V |
| Lead Finish | Gold |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Operating Temperature | -40 to 125 °C |
| Power Supply Type | Single |
| MSL Level | 2 |
| Pin Count | 5 |
| Mounting | Surface Mount |
| Screening Level | Extended |
| Minimum CMRR | 80 dB |
| Product Dimensions | 2.9 x 1.6 x 1.15 mm |
| Maximum Single Supply Voltage | 18 V |
| Rail to Rail | No |
| Supplier Package | SOT-23 |
| Number of Channels per Chip | 1 |
| Package | 5SOT-23 |
| Replacement Part Number | PART-INA194AQDBVRQ1 |
| Weight | Contact us |
| Country of Origin | - |
