Please contact us for more photos of INA103KU 1K
| Part Number | INA103KU 1K |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 587820 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp INSTR Amp Single \u00b125V 16-Pin SOIC T R |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | INA103KU 1K |
| Datasheet download |  INA103KU 1K.pdf |
| Part Number | INA103KU 1K |
|---|---|
| Max Processing Temp | 260|300 |
| Mounting | Surface Mount |
| Product Dimensions | 10.28 x 7.52 x 2.35 mm |
| Number of Channels per Chip | 1 |
| Type | Instrumentation Amplifier |
| Supplier Package | SOIC |
| Maximum Voltage Gain | 60 dB |
| Maximum Input Bias Current | 12@±15V uA |
| Power Supply Type | Dual |
| MSL Level | 3 |
| Rad Hard | No |
| Lead Finish | Gold |
| Rail to Rail | No |
| Maximum Dual Supply Voltage | ±25 V |
| Pin Count | 16 |
| Minimum Dual Supply Voltage | ±9 V |
| Minimum CMRR | 100 dB |
| Operating Temperature | -40 to 85 °C |
| Package | 16SOIC |
| Replacement Part Number | PART-INA103KU 1K |
| Weight | Contact us |
| Country of Origin | - |
