DS99R421QSQ NOPB Texas Instruments

Please contact us for more photos of DS99R421QSQ NOPB

Part Number	DS99R421QSQ NOPB
Manufacturer	Texas Instruments
Quantity in stock	872130 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LVDS Flat Panel Display 1.15V 36-Pin LLP EP T R
Category	Interface IC
Family	LVDS
ROHS Compliant	Yes
MSL Level	DS99R421QSQ NOPB
Datasheet download	DS99R421QSQ NOPB.pdf

Request Quotation for DS99R421QSQ NOPB

DS99R421QSQ NOPB Specifications

Part Number	DS99R421QSQ NOPB
Minimum Operating Supply Voltage	3 V
Number of Elements per Chip	1
Output Type	Flat Panel Display
Maximum Operating Supply Voltage	3.6 V
Lead Finish	Tin
Mounting	Surface Mount
Pin Count	36
Maximum Differential Output Voltage	1.15 V
Operating Temperature	-40 to 105 °C
Number of Receivers	4
Number of Drivers	1
Input Type	LVDS
Maximum Input Current	10 uA
Differential Input High Threshold Voltage	0.1 V
Rad Hard	No
Supplier Package	LLP EP
Product Dimensions	6 x 6 x 0.8 mm
Max Processing Temp	260
Typical Operating Supply Voltage	3.3 V
Differential Input Low Threshold Voltage	-0.1 V
MSL Level	3
Package	36LLP EP
Replacement Part Number	PART-DS99R421QSQ NOPB
Weight	Contact us
Country of Origin	-
