DS90LV048ATMX NOPB Texas Instruments

Please contact us for more photos of DS90LV048ATMX NOPB

Part Number	DS90LV048ATMX NOPB
Manufacturer	Texas Instruments
Quantity in stock	533590 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LVDS Receiver 16-Pin SOIC N T R
Category	Interface IC
Family	LVDS
ROHS Compliant	Yes
MSL Level	DS90LV048ATMX NOPB
Datasheet download	DS90LV048ATMX NOPB.pdf

Request Quotation for DS90LV048ATMX NOPB

DS90LV048ATMX NOPB Specifications

Part Number	DS90LV048ATMX NOPB
Maximum Power Dissipation	1025 mW
Screening Level	Industrial
Maximum Propagation Delay Time	2.7 ns
Pin Count	16
Input Type	LVDS
Differential Input Low Threshold Voltage	-0.1 V
Number of Drivers	4
Maximum Input Current	20 uA
Output Type	Receiver
Product Dimensions	9.91 x 3.91 x 1.45 mm
Minimum Operating Supply Voltage	3 V
Supplier Package	SOIC N
Transmission Data Rate	400 Mbps
Number of Receivers	4
Typical Operating Supply Voltage	3.3 V
Number of Elements per Chip	4
Differential Input High Threshold Voltage	0 V
Rad Hard	No
Operating Temperature	-40 to 85 °C
Max Processing Temp	260
Lead Finish	Matte Tin
MSL Level	1
Maximum Operating Supply Voltage	3.6 V
Mounting	Surface Mount
Package	16SOIC N
Replacement Part Number	PART-DS90LV048ATMX NOPB
Weight	Contact us
Country of Origin	-
