Please contact us for more photos of ADS8344E
| Part Number | ADS8344E |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 827580 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 100ksps 16-bit Serial 20-Pin SSOP Tube |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | ADS8344E |
| Datasheet download |  ADS8344E.pdf |
| Part Number | ADS8344E |
|---|---|
| MSL Level | 2 |
| Single-Ended Input | Yes |
| Input Signal Type | Single-Ended|Differential |
| Architecture | SAR |
| Sample and Hold | Yes |
| Mounting | Surface Mount |
| Differential Nonlinearity | ±2 LSB |
| Polarity of Input Voltage | Unipolar |
| Integral Nonlinearity Error | 12 LSB |
| Number of Analog Inputs | 8|4 |
| Product Dimensions | 8.65 x 3.9 x 1.5 mm |
| Pin Count | 20 |
| Full Scale Error | 0.05 % of FSR |
| Input Type | Voltage |
| Voltage Supply Source | Single |
| No Missing Codes | 14 Bit |
| Digital Supply Support | No |
| Lead Finish | Gold |
| Resolution | 16 Bit |
| Rad Hard | No |
| Voltage Reference | External |
| Sampling Rate | 100 ksps |
| Max Processing Temp | 260 |
| Supplier Package | SSOP |
| Maximum Single Supply Voltage | 5.25 V |
| Differential Input | Yes |
| Typical Power Dissipation | 7.5 mW |
| Maximum Power Dissipation | 10 mW |
| Digital Interface Type | Serial (4-Wire) |
| Typical Single Supply Voltage | 3.3|5 V |
| Minimum Single Supply Voltage | 2.7 V |
| Input Voltage | 2.7/5 V |
| Number of ADCs | 1 |
| Operating Temperature | -40 to 85 °C |
| Package | 20SSOP |
| Replacement Part Number | PART-ADS8344E |
| Weight | Contact us |
| Country of Origin | - |
