Please contact us for more photos of ADS7869IPZTR
| Part Number | ADS7869IPZTR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 261790 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | AFE General Purpose 3ADC 12-Bit 3.3V 5V 100-Pin TQFP T R |
| Category | Communication |
| Family | Analog Front End |
| ROHS Compliant | Yes |
| MSL Level | ADS7869IPZTR |
| Datasheet download |  ADS7869IPZTR.pdf |
| Part Number | ADS7869IPZTR |
|---|---|
| Interface Type | Serial (SPI) |
| Mounting | Surface Mount |
| Number of ADC Inputs | 12 |
| Product Dimensions | 14 x 14 x 1 mm |
| Pin Count | 100 |
| Type | CCD |
| Resolution | 12 Bit |
| Minimum Operating Supply Voltage | 2.7|4.5 V |
| Maximum Operating Supply Voltage | 5.5 V |
| Typical Operating Supply Voltage | 3.3|5 V |
| Number of Channels per Chip | 3 |
| Number of ADCs | 3 |
| Sampling Rate | 1000 ksps |
| Category | General Purpose |
| Typical Supply Current | 45 mA |
| Supplier Package | TQFP |
| MSL Level | 4 |
| Lead Finish | Gold |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Power Supply Type | Analog |
| Package | 100TQFP |
| Replacement Part Number | PART-ADS7869IPZTR |
| Weight | Contact us |
| Country of Origin | - |
