Please contact us for more photos of ADS1259QPWRQ1
| Part Number | ADS1259QPWRQ1 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 890670 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single Delta-Sigma 14.4ksps 24-bit Serial 20-Pin TSSOP T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | ADS1259QPWRQ1 |
| Datasheet download |  ADS1259QPWRQ1.pdf |
| Part Number | ADS1259QPWRQ1 |
|---|---|
| Maximum Single Supply Voltage | 5.25 V |
| Maximum Power Dissipation | 28 mW |
| Rad Hard | No |
| Voltage Supply Source | Analog|Digital |
| Minimum Single Supply Voltage | 2.7|4.75 V |
| Differential Input | Yes |
| Number of ADCs | 1 |
| Sample and Hold | No |
| Number of Analog Inputs | 1 |
| Voltage Reference | Internal|External |
| No Missing Codes | 24 Bit |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Resolution | 24 Bit |
| Pin Count | 20 |
| MSL Level | 1 |
| Supplier Package | TSSOP |
| Full Scale Error | 0.5 % of FSR |
| Screening Level | Automotive |
| Typical Power Dissipation | 13 mW |
| Digital Interface Type | Serial (SPI) |
| Sampling Rate | 14.4 ksps |
| Integral Nonlinearity Error | ±10 ppm |
| Input Voltage | ±2.5 V |
| Product Dimensions | 6.6(Max) x 4.5(Max) x 1.05(Max) |
| Digital Supply Support | Yes |
| Typical Single Supply Voltage | 3.3|5 V |
| Typical Dual Supply Voltage | ±2.5 V |
| Input Type | Voltage |
| Lead Finish | Gold Over Nickel Palladium |
| Architecture | Delta-Sigma |
| Operating Temperature | -40 to 125 °C |
| Single-Ended Input | Yes |
| Polarity of Input Voltage | Unipolar|Bipolar |
| Input Signal Type | Differential |
| Package | 20TSSOP |
| Replacement Part Number | PART-ADS1259QPWRQ1 |
| Weight | Contact us |
| Country of Origin | - |
