| Part Number | ADS1211E |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 517590 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single Delta-Sigma 16ksps 24-bit Serial 28-Pin SSOP Tube |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | ADS1211E |
| Datasheet download |  ADS1211E.pdf |
| Part Number | ADS1211E |
|---|---|
| Input Voltage | 5|±10 V |
| Sampling Rate | 16 ksps |
| Input Signal Type | Single-Ended|Differential |
| Minimum Single Supply Voltage | 4.75 V |
| Mounting | Surface Mount |
| Input Type | Voltage |
| Resolution | 24 Bit |
| Differential Nonlinearity | ±1 LSB |
| Voltage Reference | Internal|External |
| MSL Level | 1 |
| Typical Single Supply Voltage | 5 V |
| Product Dimensions | 10.2 x 5.3 x 1.95 mm |
| Pin Count | 28 |
| No Missing Codes | 22 Bit |
| Single-Ended Input | Yes |
| Typical Power Dissipation | 37 mW |
| Sample and Hold | No |
| Lead Finish | Gold |
| Number of ADCs | 1 |
| Operating Temperature | -40 to 85 °C |
| Number of Analog Inputs | 4 |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Polarity of Input Voltage | Unipolar|Bipolar |
| Voltage Supply Source | Analog and Digital |
| Digital Supply Support | Yes |
| Supplier Package | SSOP |
| Integral Nonlinearity Error | 0.0015 % of FSR |
| Maximum Power Dissipation | 60 mW |
| Architecture | Delta-Sigma |
| Maximum Single Supply Voltage | 5.25 V |
| Differential Input | Yes |
| Digital Interface Type | Serial (2-Wire, 3-Wire, 4-Wire, SPI) |
| Package | 28SSOP |
| Replacement Part Number | PART-ADS1211E |
| Weight | Contact us |
| Country of Origin | - |
