ADCS7477AIMFX NOPB Texas Instruments

ADCS7477AIMFX NOPB Images

Please contact us for more photos of ADCS7477AIMFX NOPB

Part Number ADCS7477AIMFX NOPB
Manufacturer Texas Instruments
Quantity in stock 342610 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description ADC Single SAR 1Msps 10-bit Serial 6-Pin SOT-23 T R
Category Data Conversion IC
Family ADC
ROHS Compliant Yes
MSL Level ADCS7477AIMFX NOPB
Datasheet download ADCS7477AIMFX NOPB.pdf
Request Quotation for ADCS7477AIMFX NOPB

ADCS7477AIMFX NOPB Specifications

Part Number ADCS7477AIMFX NOPB
Architecture SAR
Product Dimensions 2.92 x 1.6 x 1.02 mm
Resolution 10 Bit
Differential Input No
Sample and Hold Yes
No Missing Codes 10 Bit
Lead Finish Tin
Pin Count 6
Digital Supply Support No
Sampling Rate 1 Msps
Typical Single Supply Voltage 3.3|5 V
Voltage Supply Source Single
Maximum Single Supply Voltage 5.25 V
Input Type Voltage
Digital Interface Type Serial (3-Wire, SPI, QSPI, Microwire)
Number of ADCs 1
Minimum Single Supply Voltage 2.7 V
Integral Nonlinearity Error ±0.7 LSB
Signal to Noise Ratio 62 dB
Supplier Package SOT-23
Input Signal Type Single-Ended
Mounting Surface Mount
Rad Hard No
Operating Temperature -40 to 85 °C
Screening Level Extended Industrial
Max Processing Temp 260
MSL Level 1
Polarity of Input Voltage Unipolar
Single-Ended Input Yes
Number of Analog Inputs 1
Differential Nonlinearity ±0.7 LSB
Input Voltage 5.25 V
Full Scale Error ±1 LSB
Voltage Reference Supply
Package 6SOT-23
Replacement Part Number PART-ADCS7477AIMFX NOPB
Weight Contact us
Country of Origin -
