Please contact us for more photos of ADC101S051CIMFX NOPB
| Part Number | ADC101S051CIMFX NOPB |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 510830 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 500ksps 10-bit Serial 6-Pin SOT-23 T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | ADC101S051CIMFX NOPB |
| Datasheet download |  ADC101S051CIMFX NOPB.pdf |
| Part Number | ADC101S051CIMFX NOPB |
|---|---|
| Number of ADCs | 1 |
| Resolution | 10 Bit |
| Differential Nonlinearity | ±0.6 LSB |
| Integral Nonlinearity Error | ±0.7 LSB |
| Maximum Single Supply Voltage | 5.25 V |
| Typical Single Supply Voltage | 3.3|5 V |
| Operating Temperature | -40 to 85 °C |
| Minimum Single Supply Voltage | 2.7 V |
| Max Processing Temp | 260 |
| Full Scale Error | ±1 LSB |
| Product Dimensions | 2.92 x 1.6 x 1.02 mm |
| Input Signal Type | Single-Ended |
| Rad Hard | No |
| Voltage Supply Source | Single |
| Sampling Rate | 500 ksps |
| Single-Ended Input | Yes |
| Sample and Hold | Yes |
| Number of Analog Inputs | 1 |
| Polarity of Input Voltage | Unipolar |
| Mounting | Surface Mount |
| Input Type | Voltage |
| Differential Input | No |
| Pin Count | 6 |
| Voltage Reference | Supply |
| Architecture | SAR |
| Signal to Noise Ratio | 61.6 dB |
| Digital Supply Support | No |
| No Missing Codes | 10 Bit |
| Digital Interface Type | Serial (3-Wire, SPI, QSPI, Microwire) |
| MSL Level | 1 |
| Screening Level | Industrial |
| Supplier Package | SOT-23 |
| Input Voltage | 5.25 V |
| Lead Finish | Matte Tin |
| Package | 6SOT-23 |
| Replacement Part Number | PART-ADC101S051CIMFX NOPB |
| Weight | Contact us |
| Country of Origin | - |
