MINISMDC300F-2 TE Connectivity

MINISMDC300F-2 Images

Please contact us for more photos of MINISMDC300F-2

Part Number MINISMDC300F-2
Manufacturer TE Connectivity
Quantity in stock 155130 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description PTC Resettable Fuse 100A 6VDC T R
Category Circuit Protection
Family PTC Resettable Fuse
ROHS Compliant Yes
MSL Level MINISMDC300F-2
Datasheet download MINISMDC300F-2.pdf
Request Quotation for MINISMDC300F-2

MINISMDC300F-2 Specifications

Part Number MINISMDC300F-2
Rad Hard No
Maximum Trip Time 5@8A
Maximum Post Trip Resistance 0.036
Minimum Initial Resistance 0.011
Typical Power Dissipation 1
Hold Current 3
Mounting Surface Mount
Product Dimensions 4.73 x 3.41 x 0.76 mm
Maximum Voltage Rating 6
Operating Temperature -40 to 85
Number of Terminals 2
Agency Approvals CSA/UL
Trip Current 6 A
Maximum Current Rating 100
Product Depth 3.41(Max) mm
Product Height 0.76(Max) mm
Product Length 4.73(Max) mm
Replacement Part Number PART-MINISMDC300F-2
Weight Contact us
Country of Origin -
