Part Number | 796642-7 |
---|---|
Manufacturer | TE Connectivity |
Quantity in stock | 276380 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Shrouded Header HDR 7 POS 5mm Solder ST Thru-Hole |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | 796642-7 |
Datasheet download | ![]() |
Part Number | 796642-7 |
---|---|
Housing Material | Polyamide 6/6 |
Max Processing Temp | 240 |
Body Orientation | Straight |
Mounting | Through Hole |
Termination Method | Solder |
Gender | HDR |
Contact Plating | Tin |
Type | Shrouded Header |
Product Dimensions | 37 x 8.35 x 12 mm |
Housing Color | Green |
Number of Rows | 1 |
Rad Hard | No |
Pitch | 5 mm |
Contact Material | Phosphor Bronze |
Maximum Voltage Rating | 300 |
Maximum Current Rating | 15/Contact |
Product Depth | 8.35 mm |
Product Height | 12 mm |
Product Length | 37 mm |
Replacement Part Number | PART-796642-7 |
Weight | Contact us |
Country of Origin | - |
