Please contact us for more photos of 6-104071-0
| Part Number | 6-104071-0 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 289660 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 8 POS 1.27mm Solder ST Thru-Hole Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 6-104071-0 |
| Datasheet download |  6-104071-0.pdf |
| Part Number | 6-104071-0 |
|---|---|
| Housing Material | Thermoplastic |
| Pitch | 1.27 mm |
| Product Dimensions | 16.35 x 6.19 x 9.9 mm |
| Max Processing Temp | 240|245|260|265 |
| Mounting | Through Hole |
| Contact Material | Phosphor Bronze |
| Contact Plating | Gold Over Nickel |
| Rad Hard | No |
| Lead Finish | Tin |
| Operating Temperature | -65 to 105 °C |
| Gender | HDR |
| Termination Method | Solder |
| Housing Color | Black |
| Body Orientation | Straight |
| Product Depth | 6.19 mm |
| Product Height | 9.9 mm |
| Product Length | 16.35 mm |
| Replacement Part Number | PART-6-104071-0 |
| Weight | Contact us |
| Country of Origin | - |
