Please contact us for more photos of 5555140-2
| Part Number | 5555140-2 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 152640 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn RJ-14 F 6 POS 2.54mm Solder RA Thru-Hole 4 Terminal 1 Port Tray Cat 3 |
| Category | Connectors |
| Family | Connector Telephone and Telecom |
| ROHS Compliant | Yes |
| MSL Level | 5555140-2 |
| Datasheet download |  5555140-2.pdf |
| Part Number | 5555140-2 |
|---|---|
| Termination Method | Solder |
| Body Orientation | Right Angle |
| Mounting | Through Hole |
| Operating Temperature | -40 to 70 °C |
| Lead Finish | Tin |
| Product Dimensions | 15.88 x 18.54 x 12.7 mm |
| Housing Material | Polybutylene Terephthalate |
| Max Processing Temp | 240|260|265 |
| Rad Hard | No |
| Contact Material | Phosphor Bronze |
| Gender | F |
| Family Name | RJ45 Modular Jacks & Plugs |
| Contact Plating | Gold Over Nickel |
| Pitch | 2.54 mm |
| Product Depth | 18.54 mm |
| Product Height | 12.7 mm |
| Product Length | 15.88 mm |
| Replacement Part Number | PART-5555140-2 |
| Weight | Contact us |
| Country of Origin | - |
