Part Number 5536614-1
Manufacturer TE Connectivity
Quantity in stock 602160 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conn Backplane Power RCP 8 POS 2mm Press Fit RA Thru-Hole 24 Terminal 1 Port
Category Connectors
Family Connector Power
ROHS Compliant Yes
MSL Level 5536614-1
Datasheet download 5536614-1.pdf
Request Quotation for 5536614-1

5536614-1 Specifications

Part Number 5536614-1
Termination Method Press Fit
Number of Terminals 24
Pitch 2 mm
Number of Contacts 8
Mounting Through Hole
Gender RCP
Number of Ports 1
Body Orientation Right Angle
Product Dimensions 11.88 x 20.45 x 11.8 mm
Contact Plating Gold Over Palladium Nickel Over Nickel/Gold Over Nickel
Rad Hard No
Contact Material Phosphor Bronze
Type Backplane Power
Housing Material Liquid Crystal Polymer
Product Depth 20.45 mm
Product Height 11.8 mm
Product Length 11.88 mm
Replacement Part Number PART-5536614-1
Weight Contact us
Country of Origin -
