Part Number | 5414363-4 |
---|---|
Manufacturer | TE Connectivity |
Quantity in stock | 552460 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn SMB PL 0Hz to 4GHz 50Ohm Crimp RA Cable Mount Gold Over Nickel |
Category | Connectors |
Family | Connector RF |
ROHS Compliant | Yes |
MSL Level | 5414363-4 |
Datasheet download | ![]() |
Part Number | 5414363-4 |
---|---|
Type | SMB |
Operating Temperature | -65 to 165 °C |
Product Dimensions | 13.71 x 16.38 mm |
Contact Material | Brass |
Body Orientation | Right Angle |
Termination Method | Crimp |
Terminate To | Coaxial Cable |
Operating Frequency | 0 to 4 GHz |
Impedance | 50 |
Rad Hard | No |
Contact Plating | Gold Over Nickel |
Mounting | Cable Mount |
Gender | PL |
Product Diameter | 6.35 mm |
Product Height | 16.38 mm |
Product Length | 13.71 mm |
Replacement Part Number | PART-5414363-4 |
Weight | Contact us |
Country of Origin | - |
