Part Number | 5353184-8 |
---|---|
Manufacturer | TE Connectivity |
Quantity in stock | 706830 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Board to Board PL 100 POS 0.6mm Solder ST SMD T R |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | 5353184-8 |
Datasheet download | ![]() |
Part Number | 5353184-8 |
---|---|
Number of Contacts | 100 |
Gender | PL |
Packaging | Tape and Reel |
Pitch | 0.6 mm |
Lead Free | Yes |
Number of Rows | 2 |
Contact Plating | Gold Over Nickel |
Operating Temperature | -40 to 85 °C |
Contact Material | Copper Alloy |
Housing Material | Thermoplastic |
Rad Hard | No |
Mounting | Surface Mount |
Maximum Current Rating | 0.5 A |
Maximum Voltage Rating | 50 Vac |
Termination Method | Solder |
Family | 5353184 |
Type | Board to Board |
Body Orientation | Straight |
Product Depth | 6.2 mm |
Product Height | 3.45 mm |
Product Length | 56 mm |
Replacement Part Number | PART-5353184-8 |
Weight | Contact us |
Country of Origin | - |
