Part Number | 5179031-4 |
---|---|
Manufacturer | TE Connectivity |
Quantity in stock | 515740 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Fine Pitch Connector PL 100 POS 0.8mm Solder ST SMD Tube |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | 5179031-4 |
Datasheet download | ![]() |
Part Number | 5179031-4 |
---|---|
Termination Method | Solder |
Housing Color | Natural |
Mounting | Surface Mount |
Product Dimensions | 45.8 x 6 x 7.6 mm |
Lead Finish | Tin |
Max Processing Temp | 245|260 |
Body Orientation | Straight |
Pitch | 0.8 mm |
Contact Material | Brass |
Family Name | Free Height (FH) Board-to-Board Connectors |
Contact Plating | Gold Over Nickel |
Operating Temperature | -40 to 85 °C |
Rad Hard | No |
Gender | PL |
Housing Material | Liquid Crystal Polymer |
Product Depth | 6 mm |
Product Height | 7.6 mm |
Product Length | 45.8 mm |
Replacement Part Number | PART-5179031-4 |
Weight | Contact us |
Country of Origin | - |
