Please contact us for more photos of 3-644313-3
| Part Number | 3-644313-3 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 334330 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn IDC Connector F 3 POS 2.54mm IDT RA Cable Mount Loose Piece |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 3-644313-3 |
| Datasheet download |  3-644313-3.pdf |
| Part Number | 3-644313-3 |
|---|---|
| Contact Material | Copper Alloy |
| Contact Plating | Tin Over Nickel |
| Pitch | 2.54 mm |
| Rad Hard | No |
| Mounting | Cable Mount |
| Gender | F |
| Operating Temperature | -55 to 105 °C |
| Housing Material | Nylon |
| Housing Color | Black |
| Termination Method | IDT |
| Body Orientation | Right Angle |
| Product Dimensions | 7.62 x 6.99 x 13.21 mm |
| Lead Finish | Tin |
| Product Depth | 6.99 mm |
| Product Height | 13.21 mm |
| Product Length | 7.62 mm |
| Replacement Part Number | PART-3-644313-3 |
| Weight | Contact us |
| Country of Origin | - |
