Part Number | 3-284932-5 |
---|---|
Manufacturer | TE Connectivity |
Quantity in stock | 285880 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn IDC Connector F 5 POS 2.5mm IDT RA Cable Mount |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | 3-284932-5 |
Datasheet download | ![]() |
Part Number | 3-284932-5 |
---|---|
Type | IDC Connector |
Housing Color | Red |
Pitch | 2.5 mm |
Number of Rows | 1 |
Rad Hard | No |
Gender | F |
Mounting | Cable Mount |
Contact Material | Phosphor Bronze |
Maximum Current Rating | 2 A |
Package Dimensions | 14.9 x 10.1 x 7.35 mm |
Number of Contacts | 5 |
Pin Count | 5 |
Maximum Contact Resistance | 10 MOhm |
Maximum Voltage Rating | 63 Vac |
Termination Method | IDT |
Housing Material | Polybutylene Terephthalate |
Contact Plating | Tin |
Body Orientation | Right Angle |
Operating Temperature | -40 to 110 °C |
Lead Finish | Tin |
Product Depth | 10.1 mm |
Product Height | 7.35 mm |
Product Length | 14.9 mm |
Replacement Part Number | PART-3-284932-5 |
Weight | Contact us |
