Please contact us for more photos of 292161-6
| Part Number | 292161-6 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 655440 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 6 POS 2mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 292161-6 |
| Datasheet download |  292161-6.pdf |
| Part Number | 292161-6 |
|---|---|
| Housing Color | Natural |
| Lead Finish | Tin |
| Termination Method | Solder |
| Family Name | AMP CT Wire-to-Board Connectors |
| Pitch | 2 mm |
| Mounting | Through Hole |
| Body Orientation | Straight |
| Contact Material | Brass |
| Contact Plating | Tin |
| Gender | HDR |
| Max Processing Temp | 240|260|265 |
| Product Dimensions | 13.8 x 3.6 x 6.8 mm |
| Housing Material | Nylon 6/6 |
| Rad Hard | No |
| Operating Temperature | -30 to 105 °C |
| Product Depth | 3.6 mm |
| Product Height | 6.8 mm |
| Product Length | 13.8 mm |
| Replacement Part Number | PART-292161-6 |
| Weight | Contact us |
| Country of Origin | - |
